Description
The Dayliff Range of portable petrol generators are dependable, quality products specially designed for mains standby and remote site power supply applications. Particular features include:
- Reliable and economical air cooled OHV petrol engines equipped with large size exhausts and air cleaners for low noise operation.
- High efficiency square core alternators providing increased power output and enabling operation of sensitive electronic equipment.
- DC output for charging.
- Strong tubular frame for protection and ease of handling(not DG950P and DG11000PS).
- Integrated control panel with voltmeter for operational convenience.
- Fuseless type over current protection.
- Oil alert system to stop engine in the event of low oil level(not DG950P).
High capacity fuel tank for extended operation (not DG950P) Dayliff generators are of compact design and their advanced features make them suitable for all small scale power supply applications.
| Generator Information | |
| Model | DG5000P |
| Output – Rated(kVA) | 4 |
| Output – Max(kVA) | 4,5 |
| Engine Model | LT390,4T |
| Engine Capacity(cc) | 389 |
| Engine Max Power(HP) | 13 |
| Speed | 3000rpm |
| Fuel Tank Capacity(L) | 25 |
| Operating Period | 5Hrs |
| Starter | Electric |
| Derating | Given outputs are sea level ratings. Sets should be derated at 1% for every 100m higher than 100m above sea level, and 2% for every 5° C temperature increase above 20°C |
| Noise Level | Acoustic Set with AMF, noise level: 70dBA@7m |
| Dimensions & Weights | |
| Dimension(mm) L | 650 |
| Model | DG5000P |
| Dimension(mm) H | 550 |
| W (mm) | 512 |
| Weight (kg) | 74.5 |
| Electrical Data | |
| Alternator | Brushless, self exciting, 2 pole |
| Power Output | 50Hz, 240V, single phase |
| Voltage Regulator | AVR |
| Power Factor | 1 |
